HEIDENHAIN MANUALPLUS 620 Technical Manual

January 2012 8.1 PLC Functions 1485
Note
More information about programming with structures is provided in the
online help of PLCdesignNT.
;------------------------------------
LBL Override potentiometer moved
L ApiSpin.NN_SpiOverrideInput
== WL_S_override_old
A MG_S_Nact_equal_to_Nnom
A ApiSpin.NN_SpiSpeedOK
R ML_S_override_moved
L ApiSpin.NN_SpiOverrideInput
<> WL_S_override_old
A ML_S_startup_completed
S ML_S_override_moved
L MG_spindle_speed_N_ok
S ML_S_startup_completed
;------------------------------------
L ML_Clampingmode_off[X]
O ApiAxis[X].PP_AxTraverseNeg
O ApiAxis[X].PP_AxTraversePos
O[
LN ApiAxis[X].NN_AxInPosition
AN ApiAxis[X].NN_AxDriveOn]
.
.
.
Symbolic operand
of API 3.0
Symbolic operand
of API 3.0
Symbolic
operands of
API 3.0, indexed
access
Abbreviated structure
symbol of the
respective operand
group
