1574 HEIDENHAIN Technical Manual MANUALplus 620
8.8 T Functions (T Strobe)
T functions are channel-sensitive. T functions are configured in two steps:
In the channel-sensitive parameter MP_tStrobes, you define key names for
the T functions. In this way, you assign the T functions to the machining
channel.
You configure the T functions in the parameter object System/PLC/
CfgPlcTStrobe.
8.8.1 Assigning T functions to the machining channels
MP_tStrobes
T strobe description of this machining channel
Format: Array [0..18]
Input: Key name of the T strobes used in this machining channel
Default: [0]: ToolCall0
[1]: ToolCall
[2]: ToolDef
Access: LEVEL3
Reaction: RESET
In the marker defined in MP_unitOfMeasure, the PLC is informed of the unit
of measure used in the NC program when M, S, T or alias strobes are
executed (see "MP_unitOfMeasure" on page 1548).
Settings in the configuration editor MP number
Channel
ChannelSettings
[Key name of the channel]
CfgPlcStrobes
tStrobes
unitOfMeasure
201603
201605
