7.6.3 Traverse per handwheel revolution
The distance covered by an axis per handwheel revolution depends on the
traverse per handwheel revolution and the handwheel transmission ratio.
In MP_distPerRevol, define the distance traversed per handwheel
revolution for each axis moved by handwheel.
In MP_speedFactor, define the handwheel transmission for three
transmission ratios.
MP_distPerRevol
Traverse per handwheel revolution
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.000 000 001 to max. value [mm]
Default: 1 [mm]
Access: LEVEL3
Reaction: NOTHING
MP_speedFactor
Handwheel transmission ratio
Available from NCK software version: 597 110-01.
Format: Array [0...2]
Input: 0 to 100 [%]
[0] = First ratio in [%]
[1] = Second ratio in [%]
[2] = Third ratio in [%]
Default: 1, 10 and 100 [%]
Access: LEVEL3
Reaction: RUN
The transmission ratio is set either at the control panel or directly on the
handwheel.
Settings in the configuration editor MP number
System
CfgHandwheel
speedFactor 100607
Axes
ParameterSets
[Key name of the parameter set]
CfgAxisHandwheel
distPerRevol 400203
