1408 HEIDENHAIN Technical Manual MANUALplus 620
7.11.9 Conversions
Conversions are required in order to mirror the working space. Example:
Reversing the direction of rotation for circular arcs during machining in front of
or behind the turning center, or when machining the rear face.
If the conversion table is active, the interpreter replaces a function listed in
G_ORG/M_ORG with the corresponding function from G_CONV/ M_CONV.
The conversion lists are stored in files. They are configured by HEIDENHAIN.
Conversion list 1 has the following structure:
The conversion can only be used for DIN programs (not for cycle programs).
7.11.10 Global settings
Tool life
management
Use MP_lifeTime to switch tool-life monitoring for tool service age or
workpiece quantity on or off.
MP_lifeTime
Activate/deactivate tool life monitoring
Available from NCK software version: 597 110-01.
Format: Selection menu
Selection: ON
Monitoring on
OFF
Monitoring off
Default: ON
Access: LEVEL1
Reaction: RUN
NR G_ORG G_CONV M_ORG M_CONV
02334
13243
2 12132033
3 1312303103
4 297 97 0 0
5 397 197 0 0
Settings in the configuration editor MP number
Aggregates
General
CfgGlobalProperties
lifeTime 601801
