1516 HEIDENHAIN Technical Manual MANUALplus 620
8.3 Configuring PLC Input/Output Systems
You can configure the PLC input/output systems with HSCI interface (PL 6xxx,
UEC 11x, MB machine operating panel with connected HR handwheel) and
the PROFIBUS components using the IOconfig PC software.
The components of an HSCI/PROFIBUS system are specified in a project with
IOconfig and their arrangement is described. On the basis of this data,
IOconfig generates the IOC file (*.IOC), which contains all relevant
configuration data.
Then you transfer the IOC file to the control. Enter the path/name of the
project file in the MP_iocProject parameter. With the next start-up, the IOC
file is then read in and evaluated by the control.
MP_iocProject
Configuration file for IOC hardware (HSCI and PROFIBUS
components)
Available from NCK software version: 597 110-03.
Format: String
Input: Max. 260 characters
Path and file name of the IOC project file, for example:
%OEM%\plc\ioc\project.ioc
Default: –
Access: LEVEL3
Reaction: RESET
Settings in the configuration editor MP number
System
PLC
CfgPlcPeriphery
iocProject
iocOption
103402
103403
All information required for using the IOconfig PC software and configuring
HSCI and PROFIBUS components is contained in the IOconfig Technical
Information, which is available for registered customers from the
HEIDENHAIN FileBase on the Internet.
