January 2012 2.6 Brief Description 123
2.6.4 Accessories
41 Additional Language 530 184-xx Additional conversational language
Estonian, Korean, Latvian, Norwegian, Romanian,
Slovak, Slovenian, Turkish,
Lithuanian
42 DXF import 632 231-01 DXF import
Loading of DXF contours
55 C-axis machining 633 944-01 C-axis machining
70 Y-axis machining 661 881-01 Y-axis machining
94 Parallel axes 679 676-01 Support of parallel axes (U, V, W)
Combined display of principal axes and secondary
axes
131 Spindle synchronism 806 270-01 Spindle synchronization
(of two or more spindles)
132 Opposing spindle 806 275-01 Opposing spindle
(spindle synchronization, rear-face machining)
Option
number
Option ID Comment
Accessories MANUALplus 620
PL 6xxx PLC input/output
systems with HSCI
Up to eight PL 6xxx can be connected
PL 620x (system PL)
• Necessary once for each control system (except with UEC)
• Has connections for TS and TT touch probes
• Safety-relevant inputs/outputs
• Available for 4, 6 or 8 I/O modules
PL 610x (expansion PL)
• As addition to the system PL for increasing the number of
PLC inputs/outputs
• Available for 4, 6 or 8 I/O modules
I/O modules
• PLD-H 16-08-00
I/O module with 16 digital inputs and 8 digital outputs
• PLD-H 04-00-04
I/O module with 4 analog inputs for PT 100 thermistors and
4 analog inputs for ± 10 V
• PLD-H 00-12-00
I/O module with 12 analog outputs for ± 10 V
