HEIDENHAIN MANUALPLUS 620 Technical Manual

January 2012 7.12 Configuration of the Lathe 1431
Assign a parameter set to an axis by entering the key name of the parameter
set in MP_parList (see "Assigning parameter sets" on page 637).
The switching between gear stages is controlled by the PLC. Transfer to the
PLC a selection of the parameter sets listed in MP_parList by entering them
in MP_gearSpeed0.
The configuration object CfgFeedLimits of the respective parameter set
defines the minimum and maximum spindle shaft speed for each gear stage.
The list must be sorted in ascending order, with the smallest shaft speed at
the top. Gear ranges are not supported if the list is missing or empty.
Settings in the configuration editor MP number
Axes
PhysicalAxis
[Key name of the axis]
CfgAxis
parList
[0]: PS1_0
[1]: PS1_1
...
300107
300107
Settings in the configuration editor MP number
System
PLC
CfgPlcSStrobe
[Key name of S strobe]
parList
gearSpeed0
[0]: PS1_0
[1]: PS1_1
...
104008
104008
