1034 HEIDENHAIN Technical Manual MANUALplus 620
Tolerances for
synchronism
The control reports that the synchronism of two spindles is reached if the
spindle remains within the control window of MP_syncTolerance for the
period of time defined in MP_timeSyncOK.
In MP_syncTolerance, define the size of the control window.
In MP_timeSyncOK, define the period of time which the spindle is to
remain within the control window.
MP_syncTolerance
Angle tolerance for spindle synchronism
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.001 000 000 to 2 [°]
Default: 0.01
Access: LEVEL3
Reaction: RUN
MP_timeSyncOK
Hysteresis time for spindle synchronism
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.000 000 000 to 20 [s]
Default: 0.01 [s]
Access: LEVEL3
Reaction: RUN
Spindle
synchronism
The NC stores the spindle synchronism in the following operands.
PLC operand / Description Ty p e
NN_SpiSyncSpeed
Rotational speed synchronism active
0: Rotational speed synchronism not active
1: Rotational speed synchronism active
M
NN_SpiSyncAngle
Angle synchronism active
0: Angle synchronism not active
1: Angle synchronism active
M
NN_SpiSyncReached
Synchronism attained
0: Synchronism not reached
1: Synchronism reached
M
