HEIDENHAIN MANUALPLUS 620 Technical Manual

January 2012 2.5 Component Overview of MANUALplus 620 105
Other key symbols
Key Description
Print/Background
ID
Key Description
Print/Background
ID
No symbol
–/Black
330 816-01
No symbol
–/Gray
330 816-61
NC start
White/Green
330 816-11
NC stop
White/Red
330 816-12
NC start
White/Green
330 816-49
NC stop
White/Red
330 816-50
Feed rate 1
Black/Gray
330 816-33
Feed rate 2
Black/Gray
330 816-34
Rapid traverse
Black/Gray
330 816-35
Permissive button
White/Green
330 816-22
Permissive button
Black/Gray
330 816-90
Actual position capture
White/Black
330 816-27
–
White/Black
330 816-28
+
White/Black
330 816-29
Menu selection –>
Black/Gray
330 816-92
Menu selection <–
Black/Gray
330 816-93
0
Black/Gray
330 816-0Y
