HEIDENHAIN MANUALPLUS 620 Technical Manual

January 2012 6.22 Diagnosis with the Online Monitor (OLM) 1189
Spindle synchronism commands
Spindle synchronism
 Same direction of rotation
 Speed ratio master/slave: 1/1
Spindle synchronism
 Same direction of rotation
 Speed ratio master/slave: 1/2
Spindle synchronism
 Reversed direction of rotation
 Speed ratio master/slave: 1/1
Spindle synchronism
 Same direction of rotation
 Speed ratio master/slave: 1/1
 Angle offset: 42°
Spindle synchronism
 Reversed direction of rotation
 Speed ratio master/slave: 2/1
 Angle offset: –25°
Switch off spindle synchronism
