January 2012 6.22 Diagnosis with the Online Monitor (OLM) 1191
chainState Status of the IPO chain:
 IPO chain is "full."
 IPO chain is "empty."
 IPO chain is "almost empty" (waiting for the last
acknowledgment message)
chainCount Number of acknowledgment messages in the IPO
chain
satzCount Number of blocks in this NC program.
blockId ID of the current block
blockNumber Number of the current block (from NC program)
fileName Current NC program
syncActState  Running: Synchronization not active
 Wait SS: Waiting in Single Block mode
 Wait Sync: Waiting during the synchronization of IPO
and PLC
syncWaitFor Is only relevant if syncActState is not SyncRunning.
 Channel object
 PLC-Sync
 Step-Contrl
syncWaitId Number of the current synchronization
CH-syncIdWait Waiting ID for M97, G62, G63 (channel
synchronization), not relevant for the MANUALplus 620
CH-syncId Start ID for M97, G62, G63 (channel synchronization),
not relevant for the MANUALplus 620
eomStopId ID of the End of Move (eom) from the geometry chain
laStopId ID of the End of Move (EOM) from the real-time
LookAhead
startPath Absolute starting position of current traverse on the
path
endPath Absolute end position of current traverse on the path
pathLength Current path length
S(t) (Absolute) position on the path
Variable Display
