January 2012 8.1 PLC Functions 1505
"State" window (at
lower right)
Current status of selected HSCI/PROFIBUS component.
Value: Operand value of the terminal in decimal and hexadecimal code
Text: Error texts that appear when an error occurs; otherwise, no display.
The texts displayed are error-specific texts from the HDD/GSD file or the
error information configured in IOconfig.
Display of S status (31 bits) in HEX code. The meaning is displayed in
abbreviated form below the S status.
Comment Name of the slave (for slaves and
slave modules) or terminal description
Master entries:
• "Configuration file"
Master/slave entries:
•"Name"
• "Hardware ID"
• "Hardware serial number"
• "Firmware ID"
• "Firmware timestamp"
• "Configuration file"
Terminal entries:
• "Comment"
• "Pin name"
• "Plan page"
• "Order number"
Option Designation of the option Slave / slave module entered in "block"
Bus address HSCI/PROFIBUS address Slave entered in "HSCI/PROFIBUS address"
Slot Slot number of the slave module
Terminal Terminal number Determined from the terminals entered in "I/O
offset" and "I/O bit"
Operand Operand designation Terminal entered in "PLC operand address"
Order no. Order number "Order number" entered for the terminal
Plan page Wiring diagram page "Page" entered for the terminal
Pin name Terminal name "Pin name" entered for the terminal
Field Function Formed from...
