1572 HEIDENHAIN Technical Manual MANUALplus 620
Coded output of
spindle speed
Use the parameter MP_sCode to configure a word marker for the coded
output of the spindle speed (S code). You must output the speed code to the
spindle drive through PLC outputs.
If the speed code is changed, the NC sets the S strobe. If you acknowledge
the S code with the marker defined in MP_acknowledge, the NC program is
continued and the S strobe is reset by the NC.
If required, the programmed spindle speed is rounded off to the next standard
value by the NC and given in S code as per DIN 66025 (see the S-code table
below).
Speeds of 0 to 9000 min
–1
are possible.
Use the machine parameter MP_sCode to define a symbolic name or the
number of a word marker, in which the S code of the spindle speed is
transmitted to the PLC.
MP_sCode
Word marker for the coded output of the spindle speed
Available from NCK software version: 597 110-03.
Format: String
Input: Max. 80 characters
Enter the symbolic name (API 3.0) or the number of a word
marker (API 1.0), to which the S code of the spindle speed is
written.
Example: NP_WG_S_Code (API 3.0)
W258 (API 1.0)
Default: No value, parameter optional
Access: LEVEL3
Reaction: RESET
