608 HEIDENHAIN Technical Manual MANUALplus 620
M NN_ChnBlockScan
(M4158)
Mid-program startup (or block scan) active 597 110-01 1245
M NN_ChnBlockScanStrobe
Transfer
(M4161)
Restore status at block scan (M/S/T/Q
transfer)
597 110-01 1245
M NN_ChnProgManTraverse
(M4156)
Manual traverse of the axes active (for
lathes: inspection operation)
597 110-01 1244
M NN_ChnProgReturnContour
(M4157)
Return to contour active (after manual
traverse or block scan)
597 110-01 1244
M NN_ChnTchProbeCycle Probing process active 1381
M PP_ChnTchProbeMonitor NC stop in all operating modes if stylus is
deflected
1381
Channel – Feed rate
D NN_ChnProgFeedMinute
(D360)
Programmed feed per minute [mm/rev] 597 110-01 846
D NN_ChnProgFeedRevolution Programmed feed per revolution [mm/min] 597 110-01 846
D NN_ChnProgFeedThread Programmed feed rate per thread [mm/rev] 597 110-01 846
M NN_ChnFeedMinuteActive Feed rate per minute active 597 110-01 846
M NN_ChnFeedRevolution
Active
Feed per revolution is active 597 110-01 846
M NN_ChnFeedThreadActive Feed rate per thread active 597 110-01 846
M NN_ChnFeedRapidTraverse
Active
(M4180)
Rapid traverse active (FMAX) 597 110-04 846
D NN_ChnContourFeed
(D388)
Current contouring feed rate [mm/min] 597 110-01 846
D PP_ChnContourFeedMax
(D596)
Max. feed rate from PLC [mm/min] 597 110-01 846
D NN_ChnFeedOverrideInput
(W494)
Feed-rate override set [%] 597 110-01 1358
D PP_ChnFeedOverride
(W766)
Feed-rate override entered by the PLC [%] 597 110-01 1358
D NN_ChnRapidFeedOverride
Input
(W496)
Rapid traverse override set [%] 597 110-01 –
D PP_ChnRapidFeedOverride
(W752)
Rapid traverse override entered by the PLC
[%]
597 110-01 –
D PP_ChnConfigOverride Configurable override (e.g. rapid traverse) 597 110-01 –
M PP_ChnFeedEnable Feed-rate enable for all axes 597 110-01 852
Operand Description SW
version
Page
