January 2012 6.4 Encoders 655
External
interpolation (only
CC 61xx and
CC 424)
If you connect encoders with TTL signals and external interpolation electronics
through the TTL/1 V
PP
adapter to the control:
In MP_genExtIntPolFactor, enter the interpolation factor of the external
interpolation unit.
MP_genExtIntPolFactor
External interpolation for encoder signals
Available from NCK software version: 597 110-03.
Format: Numerical value
Input: 0 to 99
0, 1: No external interpolation (default)
Default: No value, parameter optional
Access: LEVEL3
Reaction: RUN
Settings in the configuration editor MP number
Axes
ParameterSets
[Key name of the parameter set]
CfgAxisHardware
genExtIntPolFactor 400017
