HEIDENHAIN MANUALPLUS 620 Technical Manual

January 2012 6.11 Machine Kinematics (As of NC Software 548328-03) 729
You must enter the following settings in the configuration editor in order to
configure this three-axis machine. These settings were already performed for
the factory default setting of the NC software.
Settings in the configuration editor MP number
Channels
Kinematics
CfgKinComposModel
K4_CH1_S1 (key name of kinematic model)
subKinList
[0]: TOOL_TH1
[1]: K_XYZ_CH1
[2]: K_WP_S1
activeSpindle: S1
CfgKinSimpleModel
K_XYZ_CH1 (key name of the subkinematics)
kinObjects
[0]: TransMaAxDummy2
[1]: MachAxisY1
[2]: TransMaAxDummy1
[3]: MachAxisX1
[4]: MachAxisZ1
[5]: MACH_BASE
CfgKinSimpleAxis
MachAxisX1 (key name of the machine axis)
dir: X
axisRef: X1
MachAxisY (key name of the machine axis)
dir: Y
axisRef: Y1
MachAxisZ (key name of the machine axis)
dir: Z
axisRef: Z1
CfgKinAnchor
MACH_BASE (key name of the machine base)
kindOfAnchor: MachBase
K4_CH1_S1.202901.000
K4_CH1_S1.202901.001
K4_CH1_S1.202901.002
K4_CH1_S1.202902
K_ZYX.202800
K_XYZ_CH1.202801.000
K_XYZ_CH1.202801.001
K_XYZ_CH1.202801.002
K_XYZ_CH1.202801.003
K_XYZ_CH1.202801.004
K_XYZ_CH1.202801.005
MachAxisX1.202701
MachAxisX1.202702
MachAxisY1.202701
MachAxisY1.202702
MachAxisZ1.202701
MachAxisZ1.202702
MACH_BASE.203701
Channels
ChannelSettings
CH_NC1 (Key name of the machining channel)
CfgActivateKinem
kinemToActivate: K4_CH1_S1 CH_NC1.204001
