January 2012 2.5 Component Overview of MANUALplus 620 91
I/O modules I/O modules are available with digital and analog inputs and outputs. For
partially occupied PLB basic modules, the unused slots must be occupied by
an empty housing.
PLD-H xx–xx–xx
Digital I/O module:
PLD-H 16-08-00:
I/O module with 16 digital inputs and 8
digital outputs
PLD-H 08-16-00:
I/O module with 8 digital inputs and 16
digital outputs
PLD-H 08-04-00:
I/O module with 8 digital inputs and
4 digital outputs
PLD-H 04-08-00:
I/O module with 4 digital inputs and 8
digital outputs
PLD-H 16-08-00 ID 594 243-xx
PLD-H 08-16-00 ID 650 891-xx
PLD-H 08-04-00 ID 598 905-xx
PLD-H 04-08-00 ID 727 219-xx
