January 2012 6.17 Monitoring Functions 957
This error message can be cleared, and traverse can continue.
MP_posTolerance
Positioning window
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.001 to 100.000 [mm]
Default: 0.005
Access: LEVEL3
Reaction: RUN
MP_timePosOK
Hysteresis time for "positioning window reached"
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.000 to 20.000 [s]
Default: 0.010 [s]
Access: LEVEL3
Reaction: RUN
Axis movement by
interpolator
If the interpolator wants to move the axes, the markers
NN_AxMotionRequest or NN_SpiMotionRequest are set. The PLC then
switches on the drive, activates the control loop, releases the brake, and
enables the feed rate or spindle.
If a spindle is moved by the NC and not by the PLC program, the
NN_SpiMotionRequest marker is set. This allows the PLC program to decide
when the spindle drive is to be switched on.
PLC operand / Description Ty p e
NN_AxInPosition
Axis in position
0: Axis not in positioning window
1: Axis in positioning window
M
PLC operand / Description Ty p e
NN_AxMotionRequest
Axis movement by interpolator
0: No axis movement by interpolator
1: Axis movement by interpolator
M
NN_SpiMotionRequest
Spindle movement by interpolator
0: No spindle movement by interpolator
1: Spindle movement by interpolator
M
