Intel Arria 10 User Manual

Parameters Value
RX rate match insert / delete +ve pattern (hex)
0x000a257c (/K28.5/D16.2/) (for GbE)
0x00000000 (disabled for GbE with IEEE
1588v2)
Enable rx_std_rmfifo_full port
On/Off
(option disabled for GbE with IEEE 1588v2)
Enable rx_std_rmfifo_empty port
On/Off
(option disabled for GbE with IEEE 1588v2)
PCI Express Gen3 rate match FIFO mode Bypass
Enable TX bit slip Off
Enable tx_std_bitslipboundarysel port On/Off
RX word aligner mode Synchronous state machine
RX word aligner pattern length 7
RX word aligner pattern (hex)
0x000000000000007c (Comma) (for 7-bit
aligner pattern length), 0x000000000000017c
(/K28.5/) (for 10-bit aligner pattern length)
Number of word alignment patterns to achieve sync 3
Number of invalid data words to lose sync 3
Number of valid data words to decrement error count 3
Enable fast sync status reporting for deterministic latency SM On/Off
Enable rx_std_wa_patternalign port Off
Enable rx_std_wa_a1a2size port Off
Enable rx_std_bitslipboundarysel port Off
Enable rx_bitslip port Off
Enable TX bit reversal Off
Enable TX byte reversal Off
Enable TX polarity inversion On/Off
Enable tx_polinv port On/Off
Enable RX bit reversal Off
Enable rx_std_bitrev_ena port Off
Enable RX byte reversal Off
Enable rx_std_byterev_ena port Off
Enable RX polarity inversion On/Off
Enable rx_polinv port On/Off
Enable rx_std_signaldetect port On/Off
All options under PCIe Ports Off
Related Information
Using the Arria 10 Transceiver Native PHY IP Core on page 45
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
123

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
