Parameter Value
DFE adaptation mode disabled
Number of fixed dfe taps N/A
Enable rx_pma_clkout port On/Off
Enable rx_pma_div_clkout port On/Off
rx_pma_div_clkout division factor Disabled, 1, 2, 33, 40, 66
Enable rx_pma_iqtxrx_clkout port On/Off
Enable rx_pma_clkslip port On/Off
Enable rx_pma_qpipulldn port (QPI) Off
Enable rx_is_lockedtodata port On/Off
Enable rx_is_lockedtoref port On/Off
Enable rx_set_locktodata and rx_set_locktoref ports On/Off
Enable rx_seriallpbken port On/Off
Enable PRBS verifier control and status ports On/Off
Table 94. Standard PCS Parameters
Parameters Value
Standard PCS / PMA interface width 10
FPGA fabric / Standard TX PCS interface width 8
FPGA fabric / Standard RX PCS interface width 8
Enable Standard PCS low latency mode Off
TX FIFO mode
low latency (for GbE)
register_fifo (for GbE with IEEE 1588v2)
RX FIFO mode
low latency (for GbE)
register_fifo (for GbE with IEEE 1588v2)
Enable tx_std_pcfifo_full port On/Off
Enable tx_std_pcfifo_empty port On/Off
Enable rx_std_pcfifo_full port On/Off
Enable rx_std_pcfifo_empty port On/Off
TX byte serializer mode Disabled
RX byte deserializer mode Disabled
Enable TX 8B/10B encoder On
Enable TX 8B/10B disparity control On/Off
Enable RX 8B/10B decoder On
RX rate match FIFO mode
gige (for GbE)
disabled (for GbE with IEEE 1588v2)
RX rate match insert / delete -ve pattern (hex)
0x000ab683 (/K28.5/D2.2/) (for GbE)
0x00000000 (disabled for GbE with IEEE
1588v2)
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
122

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
