Signal Name Direction Clock Domain Description
recommends that you connect it to a PLL for use with the
Triple Speed Ethernet IP function. The frequency is 125 MHz
for 1G and 156.25 MHz for 10G. This clock is driven from the
MAC.
The frequencies are the same whether or not you enable FEC.
xgmii_rx_dc[71:0
]
Output Synchronous to
xgmii_rx_clk
RX XGMII data and control for 8 lanes. Each lane consists of 8
bits of data and 1 bit of control.
xgmii_rx_clk
Input Clock signal Clock for SDR XGMII RX interface to the MAC. This clock can
be connected to the tx_div_clkout ; however, Intel
recommends that you connect it to a PLL for use with the
Triple Speed Ethernet IP function. The frequency is 125 MHz
for 1G and 156.25 MHz for 10G. This clock is driven from the
MAC.
The frequencies are the same whether or not you enable FEC.
2.6.3.5.3. XGMII Mapping to Standard SDR XGMII Data
Table 116. TX XGMII Mapping to Standard SDR XGMII Interface
The 72-bit TX XGMII data bus format is different than the standard SDR XGMII interface. This table shows the
mapping of this non-standard format to the standard SDR XGMII interface.
Signal Name SDR XGMII Signal Name Description
xgmii_tx_dc[7:0] xgmii_sdr_data[7:0]
Lane 0 data
xgmii_tx_dc[8] xgmii_sdr_ctrl[0]
Lane 0 control
xgmii_tx_dc[16:9] xgmii_sdr_data[15:8]
Lane 1 data
xgmii_tx_dc[17] xgmii_sdr_ctrl[1]
Lane 1 control
xgmii_tx_dc[25:18] xgmii_sdr_data[23:16]
Lane 2 data
xgmii_tx_dc[26] xgmii_sdr_ctrl[2]
Lane 2 control
xgmii_tx_dc[34:27] xgmii_sdr_data[31:24]
Lane 3 data
xgmii_tx_dc[35] xgmii_sdr_ctrl[3]
Lane 3 control
xgmii_tx_dc[43:36] xgmii_sdr_data[39:32]
Lane 4 data
xgmii_tx_dc[44] xgmii_sdr_ctrl[4]
Lane 4 control
xgmii_tx_dc[52:45] xgmii_sdr_data[47:40]
Lane 5 data
xgmii_tx_dc[53] xgmii_sdr_ctrl[5]
Lane 5 control
xgmii_tx_dc[61:54] xgmii_sdr_data[55:48]
Lane 6 data
xgmii_tx_dc[62] xgmii_sdr_ctrl[6]
Lane 6 control
xgmii_tx_dc[70:63] xgmii_sdr_data[63:56]
Lane 7 data
xgmii_tx_dc[71] xgmii_sdr_ctrl[7]
Lane 7 control
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
145

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
