Document
Version
Changes
Made the following changes to the Arria 10 Transceiver Protocols and PHY IP Support section:
• Updated table "Arria 10 Transceiver Protocols and PHY IP Support"
— Removed SFIS and 10G SDI from the table.
— Updated Protocol Preset, Transceiver Configuration Rule, and PCS Support for protocols in the
table.
Made the following changes to the Using the Arria 10 Transceiver Native PHY IP section:
• Updated references of MegaWizard Plug-In Manager to IP Catalog and Parameter Editor.
• Added PCS Direct block in figure "Transceiver Native PHY IP Top Level Interfaces and Functional
Blocks".
• Updated figure "Transceiver Native PHY IP GUI" for 14.0A10 release IP GUI.
• Updated General and Datapath Parameters section
— Updated parameter descriptions in table "General and Datapath Options".
— Updated parameter descriptions in table "Transceiver Configuration Rule Parameters".
• Updated PMA Parameters section
— Updated parameter descriptions in tables "TX PMA Bonding options", "TX PLL Options", "RX PMA
Parameters".
— Added description for CTLE adaptation mode and updated description for DFE adaptation
mode.
• Enhanced PCS Parameters section
— Added a new table "Enhanced PCS Parameters"
— Updated the parameter descriptions in tables "Enhanced PCS TX FIFO Parameters", "Enhanced
PCS RX FIFO Parameters", "Interlaken Frame Generator Parameters", "Interlaken Frame
Synchronizer Parameters", "10GBASE-R BER Checker Parameters", "Scrambler-Descrambler
Parameters", "Block Synchronizer Parameters", "Gearbox Parameters".
— Added descriptions in "KR-FEC Parameters" table.
• Standard PCS Parameters
— Updated the descriptions in tables "TX and RX FIFO Parameters", "Rate Match FIFO Parameters",
"Word Aligner and Bitslip Parameters", and "PCIe Ports".
• Dynamic Reconfiguration Parameters
— Removed Enable Embedded JTAG Avalon-MM Master parameter and added Altera Debug
Master Endpoint parameter and updated its description.
— Added a table for "Embedded Debug Parameters".
• Updated the figure "Directory Structure for Generated Files" in IP Core File Locations section.
• Changed "one-time" to "triggered" adaptation mode for DFE and CTLE.
Made the following changes to the Interlaken section:
• Changed parameter name in the "Signals and Ports of Native PHY IP for Interlaken" figure from
tx_bonding_clock to tx_bonding_clock[5:0].
• Updated tables in the "Native PHY IP Parameter Settings for Interlaken" section:
— Added new tables: "10GBASE-R BER Checker Parameters", "KR-FEC Parameters".
— Deleted table: "Configuration Profiles Parameters".
— Added new parameters and updated existing ones to tables: "General and Datapath
Parameters", "TX PMA Parameters", "RX PMA Parameters", "Enhanced PCS Parameters",
"Dynamic Reconfiguration Parameters".
— Updated existing parameters to tables: "Interlaken Frame Generator Parameters", "Interlaken
CRC-32 Generator and Checker Parameters".
Made the following changes to the Ethernet section:
• Initial release of the XAUI PHY IP Core section.
• Changed the bus width between the FPGA fabric and PCS, and added notes 3 and 4 to the
"Transceiver Channel Datapath and Clocking at 1250 Mbps for GbE, GbE with IEEE 1588v2" figure.
•
Provided the full hexadecimal values for rx_parallel_data, rx_patterndetect, and
rx_runningdisp in the "Decoding for GbE" figure description.
• Changed the note in the Rate Match FIFO for GbE section to clarify the case where 200 ppm total is
valid.
•
Added the pll_cal_busy circuitry, updated signals, and added a note to the "Connection
Guidelines for a GbE/GbE with IEEE 1588v2 PHY Design" figure.
• Removed the Device and speed grade parameter from the "General and Datapath Options" table.
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
344
