Intel Arria 10 User Manual

when moving from CTLE manual, DFE disabled to CTLE triggered, DFE disabled. User
need to perform read modify writes to all the register bits that differ through dynamic
reconfiguration (AVMM) interface.
Table 276. Register Map for CTLE triggered and CTLE manual settings
Register Address Register Bit Description
Value
CTLE Triggered, DFE
Disabled
CTLE Manual, DFE
Disabled
0x123
1:1 Enable Adaptation Slicers 1'b1 1'b0
2:2 Enable DFE Fix Tap 8 to 11 1'b0
3:3 Enable DFE Fix Tap 4 to 7 1'b0
0x148
0:0 Enable DFE Fix TAP 1 to 7 Adaptation 1'b0
1:1 Enable DFE Fix TAP 8 to 11 Adaptation 1'b0
2:2 Enable VREF Adaptation 1'b1 1'b0
3:3 Enable VGA Adaptation 1'b1 1'b0
4:4 Enable CTLE Adaptation 1'b1 1'b0
0x14B 7:7 Enable CTLE Adaptation 1'b1 1'b0
0x15B 4:4 Enable CTLE Adaptation 1'b1 1'b0
0x15B
0:0 Bypass DFE Fix TAP 1 to 7 Adaptation 1'b1
2:2 Bypass DFE Fix TAP 8 to 11 Adaptation 1'b1
0x15E 0:0 Bypass VREF Adaptations 1'b0 1'b1
0x160 0:0 Bypass VGA Adaptations 1'b1
0x166 0:0 Bypass Single Stage CTLE 1'b0 1'b1
0x167 0:0 Bypass 4 Stage CTLE 1'b0 1'b1
0x163 7:5 CTLE Adaptation Timer Window 3'b111
0x14D 2:0 DFE Adaptation Mode 3'b100 3'b111
0x124 5:5 Enable DFT 1'b1
0x11F 5:4 Eq_bw_sel 2'b01 (Gen3) 2'b00 (Gen1/2)
Refer to the "Arria 10 Register Map" and "Arria 10 Adaptation Tool" for details on
adaptation registers.
Related Information
• How to Enable CTLE and DFE on page 456
• Arria 10 Transceiver Register Map on page 564
6. Reconfiguration Interface and Dynamic Reconfiguration
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
532

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
