Intel Arria 10 User Manual

Parameter Value Description
Decision Feedback Equalizer
(DFE) Fixed Tap 3 Co-
efficient
radp_dfe_fxtap3_0 to
radp_dfe_fxtap3_127
Selects the co-efficient of the fixed tap 3 of the
Decision Feedback Equalizer (DFE) when
operating in manual mode.
Decision Feedback Equalizer
(DFE) Fixed Tap 4 Co-
efficient
radp_dfe_fxtap4_0 to
radp_dfe_fxtap4_63
Selects the co-efficient of the fixed tap 4 of the
Decision Feedback Equalizer (DFE) when
operating in manual mode.
Decision Feedback Equalizer
(DFE) Fixed Tap 5 Co-
efficient
radp_dfe_fxtap5_0 to
radp_dfe_fxtap5_63
Selects the co-efficient of the fixed tap 5 of the
Decision Feedback Equalizer (DFE) when
operating in manual mode.
Decision Feedback Equalizer
(DFE) Fixed Tap 6 Co-
efficient
radp_dfe_fxtap6_0 to
radp_dfe_fxtap6_31
Selects the co-efficient of the fixed tap 6 of the
Decision Feedback Equalizer (DFE) when
operating in manual mode.
Decision Feedback Equalizer
(DFE) Fixed Tap 7 Co-
efficient
radp_dfe_fxtap7_0 to
radp_dfe_fxtap7_31
Selects the co-efficient of the fixed tap 7 of the
Decision Feedback Equalizer (DFE) when
operating in manual mode.
Decision Feedback Equalizer
(DFE) Fixed Tap 8 Co-
efficient
radp_dfe_fxtap8_0 to
radp_dfe_fxtap8_31
Selects the co-efficient of the fixed tap 8 of the
Decision Feedback Equalizer (DFE) when
operating in manual mode.
Decision Feedback Equalizer
(DFE) Fixed Tap 9 Co-
efficient
radp_dfe_fxtap9_0 to
radp_dfe_fxtap9_31
Selects the co-efficient of the fixed tap 9 of the
Decision Feedback Equalizer (DFE) when
operating in manual mode.
Decision Feedback Equalizer
(DFE) Fixed Tap 10 Co-
efficient
radp_dfe_fxtap10_0 to
radp_dfe_fxtap10_31
Selects the co-efficient of the fixed tap 10 of the
Decision Feedback Equalizer (DFE) when
operating in manual mode.
Decision Feedback Equalizer
(DFE) Fixed Tap 11 Co-
efficient
radp_dfe_fxtap11_0 to
radp_dfe_fxtap11_31
Selects the co-efficient of the fixed tap 11 of the
Decision Feedback Equalizer (DFE) when
operating in manual mode.
On-Chip termination
R_ext0, r_r1, r_r2
Selects the on-chip RX differential termination.
Table 44. Generation Options
Parameter Value Description
Generate parameter
documentation file
On/Off When you turn on this option, generation produces a Comma-
Separated Value (.csv ) file with descriptions of the Transceiver
Native PHY IP parameters.
Related Information
• Analog Parameter Settings on page 585
• XCVR_A10_TX_PRE_EMP_SWITCHING_CTRL_PRE_TAP_1T on page 602
• XCVR_A10_TX_PRE_EMP_SWITCHING_CTRL_PRE_TAP_2T on page 602
• XCVR_A10_TX_PRE_EMP_SWITCHING_CTRL_1ST_POST_TAP on page 603
• XCVR_A10_TX_PRE_EMP_SWITCHING_CTRL_2ND_POST_TAP on page 604
• Reconfiguration Interface and Dynamic Reconfiguration on page 502
• Transmitter Pre-Emphasis First Pre-Tap Value on page 600
• Transmitter Pre-Emphasis Second Pre-Tap Value on page 600
• Transmitter Pre-Emphasis First Post-Tap Value on page 601
• Transmitter Pre-Emphasis Second Post-Tap Value on page 601
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
72
