Name Bit Functionality Description
[8] Synchronization header error, metaframe error,
or CRC32 error status
A logic high (1'b1) indicates
synchronization header error,
metaframe error, or CRC32 error
status.
[9] Block lock and frame lock status A logic high (1'b1) indicates that
block lock and frame lock have
been achieved.
[19:10] Unused
Table 64. Bit Encodings for 10GBASE-R , 10GBASE-KR with FEC
Name Bit Functionality
rx_control
[0]
XGMII control signal for parallel_data[7:0]
[1]
XGMII control signal for parallel_data[15:8]
[2]
XGMII control signal for parallel_data[23:16]
[3]
XGMII control signal for parallel_data[31:24]
[4]
XGMII control signal for parallel_data[39:32]
[5]
XGMII control signal for parallel_data[47:40]
[6]
XGMII control signal for parallel_data[55:48]
[7]
XGMII control signal for parallel_data[63:56]
[19:8] Unused
Table 65. Bit Encodings for Basic Single Width Mode
For basic single width mode, the total word length is 66-bit with 64-bit data and 2-bit synchronous header.
Name
Bit Functionality Description
rx_control
[1:0] Synchronous header The value 2'b01 indicates a data word. The value
2'b10 indicates a control word.
[7:2] Unused
[9:8] Synchronous header error status The value 2'b01 indicates a data word. The value
2'b10 indicates a control word.
[19:10] Unused
Table 66. Bit Encodings for Basic Double Width Mode
For basic double width mode, total word length is 66-bit with 128-bit data, and 4-bit synchronous header.
Name
Bit Functionality Description
rx_control
[1:0] Synchronous header The value 2'b01 indicates a data word. The
value 2'b10 indicates a control word.
[7:2] Unused
[8] Synchronous header error status Active-high status signal that indicates a
synchronous header error.
[9] Block lock is achieved Active-high status signal indicating when block
lock is achieved.
[11:10] Synchronous header The value 2'b01 indicates a data word. The
value 2'b10 indicates a control word.
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
85
