USB Port Specifications for the QFX Series
The following Juniper Networks USB flash drives have been tested and are officially
supported for the USB port in a QFX Series device:
•
RE-USB-1G-S—1-gigabyte (GB) USB flash drive (except QFX3100 Director device)
•
RE-USB-2G-S—2-GB USB flash drive (except QFX3100 Director device)
•
RE-USB-4G-S—4-GB USB flash drive
CAUTION: Any USB memory product not listed as supported for QFX Series
devices has not been tested by Juniper Networks. Theuse of any unsupported
USB memory product could expose your device to unpredictable behavior.
Juniper Networks TechnicalAssistance Center (JTAC)can provideonly limited
support forissues related to unsupportedhardware.We strongly recommend
that you use only supported USB flash drives.
CAUTION: Remove the USB flash drive before upgrading Junos OS or
rebooting the QFX Series device. Failure to do so could expose your device
to unpredictable behavior.
