To unpack the device:
1. Move the shipping box to a staging area as close to the installation site as possible.
Make sure there is enough space to remove components from the chassis if necessary.
While the chassis is bolted to the pallet, you can use a forklift or pallet jack to move
it.
2. Remove the cardboard cover, foam padding, and accessory box.
3. Unpack the accessory box and lay out the contents so that they are ready for use.
4. Verify that your order includes all appropriate parts. See “Parts Inventory (Packing
List) for a QFX3008-I Interconnect Device” on page 225.
5. Use a 5/16-in. open-end or socket wrench and a number 2 Phillips screwdriver to
remove the four sets of bracket bolts and screws that secure the chassis to the shipping
pallet. Store the brackets and bolts inside the accessory box.
6. Save the shipping box, pallet, and packing materials in case you need to move or ship
the device at a later time.
Related
Documentation
Mounting a QFX3008-I Interconnect Device on a Rack or Cabinet Using a Mechanical
Lift on page 234
•
Parts Inventory (Packing List) for a QFX3008-I Interconnect Device
The device shipment includes a packing list. Check the parts you receive in the shipping
crate against the items on the packing list. The packing list specifies the part number
and description of each part in your order. The parts shipped depend on the configuration
you order.
If any part on the packing list is missing, contact your customer service representative or
contact Juniper Networks customer care from within the U.S. or Canada by telephone at
1-800-638-8296. For international-dial or direct-dial options in countries without toll-free
numbers, see http://www.juniper.net/support/requesting-support.html .
Table 56 on page 225 lists the parts and their quantities in the packing list for a QFX3008-I
Interconnect device.
Table 56: Parts List for QFX3008-I Interconnect Device Configurations
QuantityComponent
1Chassis, including the midplane and rack-mounting brackets
1 (optional)Cable manager
1 (optional)Lockable front door
2Control Boards
1–816-port QSFP+ front cards
225Copyright © 2012, Juniper Networks, Inc.
Chapter 19: Installing a QFX3008-I Interconnect Device
