Figure 136: AC Three-Phase Wiring Tray LEDs on a QFX3008-I Interconnect
Device
g050161
Status LEDs
Table 78 on page 396 describes the LEDs on an AC wiring tray.
Table 78: AC Wiring Tray LEDs on a QFX3008-I Interconnect Device
DescriptionStateLED
Indicates one of the following:
Wiring tray is disconnected from power feed.
AC power input voltage is not within normal
operating range.
No AC power input.
UnlitPower (Phase 1, 2, or 3)
AC power input voltage is within normal operating
range.
Green
Related
Documentation
AC Power Specifications for a QFX3008-I Interconnect Device with Single-Phase
Wiring Trays on page 137
Power Requirements for a QFX3008-I Interconnect Device on page 139
Connecting AC Power to a QFX3008-I Interconnect Device with Single-Phase Wiring
Trays on page 239
Copyright © 2012, Juniper Networks, Inc.396
