Figure 124: Installing an SFP Transceiver in a QFX Series Device
Figure 125: Installing a QSFP+ Transceiver in a QFX Series Device
Related
Documentation
Removing a Transceiver from a QFX Series Device on page 373•
• Connecting a Fiber-Optic Cable to a QFX Series Device on page 377
Disconnecting a Fiber-Optic Cable from a QFX Series Device
QFX Series devices have field-replaceable unit (FRU) optical transceivers to which you
can connect fiber-optic cables.
Before you disconnect a fiber-optic cable from an optical transceiver installed in a QFX
Series device, ensure that you have taken the necessary precautions for safe handling
of lasers (see “Laser and LED Safety Guidelines and Warnings for the QFX Series” on
page 168).
Ensure that you have the following parts and tools available:
•
Rubber safety cap to cover the transceiver
•
Rubber safety cap to cover the fiber-optic cable connector
