Unpacking a QFX3500 Device
The QFX3500 device chassis is a rigid sheet-metal structure that houses the hardware
components. A QFX3500 device is shipped in a cardboard carton, secured with foam
packing material. The carton also contains an accessory box and quick start instructions.
CAUTION: QFX3500 devices are maximally protected inside the shipping
carton. Do not unpack the device until you are ready to begin installation.
To unpack a QFX3500 device:
1. Move the shipping carton to a staging area as close to the installation site as possible,
but where you have enough room to remove the system components.
2. Position the carton so that the arrows are pointing up.
3. Open the top flaps on the shipping carton.
4. Remove the accessory box and verify the contents against the inventory included in
the box. Table 62 on page 260 lists the inventory of components supplied with a
QFX3500 device.
5. Pull out the packing material holding the device in place.
6. Verify the chassis components received:
•
Management board
•
Two fan trays
•
One or two power supplies, depending on your order. If only one power supply is
installed, a blank panel should be installed on the second power supply slot.
7. Save the shipping carton and packing materials in case you need to move or ship the
device later.
Table 62: Inventory of Components Supplied with a QFX3500 Device
QuantityComponent
1Chassis with management board, two fan trays, and one or two power supplies
2Rear installation blades
1RJ-45 cable and RJ-45 to DB-9 adapter
48SFP/SFP+ port dust covers
4QSFP+ port dust covers
1Electrostatic discharge (ESD) grounding strap
Copyright © 2012, Juniper Networks, Inc.260
QFX3000 Hardware Documentation
