3. Mount the device by following the instructions in “Mounting a QFX3008-I Interconnect
Device on a Rack or Cabinet Using a Mechanical Lift” on page 234.
4. Connect the QFX3008-I Interconnect device to earth ground.
See “Connecting Earth Ground to a QFX3008-I Interconnect Device” on page 237.
5. Connect power to the device.
See “Connecting AC Power to a QFX3008-I Interconnect Device with Single-Phase
Wiring Trays” on page 239, “Connecting AC Power to a QFX3008-I Interconnect Device
with Three-Phase Delta Wiring Trays” on page 246, and “Connecting AC Power to a
QFX3008-I Interconnect Device with Three-Phase Wye Wiring Trays” on page 250.
6. (Optional) If you have purchased the cable management system or the lockable front
doors, install them by following the instructions in “Installing the Cable Management
System on a QFX3008-I Interconnect Device” on page 255 and “Installing the Lockable
Front Doors on a QFX3008-I Interconnect Device” on page 256.
7. See “QFX3000-G QFabric System Installation Overview” on page 209 for information
about the next steps to install and configure your QFX3000 QFabric system.
Related
Documentation
Rack Requirements for a QFX3008-I Interconnect Device on page 95•
• Cabinet Requirements for a QFX3008-I Interconnect Device on page 98
• Clearance Requirements for Airflow and Hardware Maintenance for a QFX3008-I
Interconnect Device on page 100
• Chassis Lifting Guidelines for a QFX3008-I Interconnect Device on page 175
Unpacking a QFX3008-I Interconnect Device
After you prepare the installation site as described in “Site Preparation Checklist for a
QFX3008-I Interconnect Device” on page 84, you may unpack the device.
NOTE: The device is maximally protected inside the shipping box. Do not
unpack it until you are ready to begin installation.
Before you begin, ensure that you have the following parts and tools available to unpack
the QFX3008-I Interconnect Device:
•
Phillips (+) screwdriver, number 2
•
A 5/16-in. open-end or socket wrench to remove the bracket bolts from the shipping
pallet
•
A box cutter or packing knife to slice open the tape that seals the top of the box
The device ships in a cardboard box that has a two-layer wooden pallet base with foam
cushioning between the layers. The device chassis is bolted to the pallet base. Quick
Start installation instructions and a cardboard accessory box are also included in the
shipping crate.
Copyright © 2012, Juniper Networks, Inc.224
QFX3000 Hardware Documentation
