• Connecting AC Power to a QFX3008-I Interconnect Device with Three-Phase Delta
Wiring Trays on page 246
• Connecting AC Power to a QFX3008-I Interconnect Device with Three-Phase Wye
Wiring Trays on page 250
• Connecting AC Power to a QFX3500 Device on page 265
Chassis Lifting Guidelines for a QFX3100 Director Device
The weight of a fully loaded QFX3100 Director device chassis is approximately 41.2 lb
(18.7 kg). Observe the following guidelines for lifting and moving a QFX3100 Director
device:
•
Before installing a QFX3100 Director device, read the guidelines in “Site Preparation
Checklist for a QFX3100 Director Device” on page 83 to verify that the intended site
meets the specified power, environmental, and clearance requirements.
•
Before lifting or moving the QFX3100 Director device, disconnect all external cables.
•
As when lifting any heavy object, lift most of the weight with your legs rather than your
back. Keep your knees bent and your back relatively straight and avoid twisting your
body as you lift. Balance the load evenly and be sure that your footing is solid.
Related
Documentation
General Safety Guidelines and Warnings on page 161•
• Installation Instructions Warning on page 173
• Mounting a QFX3100 Director Device on Two Posts in a Rack or Cabinet on page 215
• Mounting a QFX3100 Director Device on Four Posts in a Rack or Cabinet on page 217
Chassis Lifting Guidelines for a QFX3008-I Interconnect Device
The weight of a fully loaded QFX3008-I Interconnect device is approximately 650 lb
(295 kg). Observe the following guidelines for lifting and moving the device:
•
Before moving the device to a site, ensure that the site meets the power, environmental,
and clearance requirements specified in the “Site Preparation Checklist for a QFX3008-I
Interconnect Device” on page 84.
•
Do not attempt to lift the QFX3008-I Interconnect device by yourself. We recommend
using a mechanical lift rated for at least 750 lb (340.2 kg) to install the QFX3008
device in a rack or cabinet. If you do not have a lift rated for 750 lb (341 kg), you must
remove all components from the chassis and use a lift rated for at least 250 lb (114
kg). The weight of an empty QFX3008-I Interconnect device and midplane is
approximately 205 lb (93 kg).
WARNING: Becauseof the QFX3008-I Interconnect devicesize and weight,
werequire the use of a mechanical lift to install the QFX3008-I Interconnect
175Copyright © 2012, Juniper Networks, Inc.
Chapter 15: Installation and Maintenance Safety Information
