Table 4: FRUs in a QFX3100 Director Device
Action to Take Before Removing the ComponentFRU
You must power off the QFX3100 Director device offline before replacing a
network module. See “Removing a Network Module from a QFX3100 Director
Device” on page 315.
Network modules
None.Hard disk drive (HDD) modules
None.Power supplies
None.Fan modules
NOTE: If you have a Juniper Networks J-Care service contract, register any
addition, change, or upgrade of hardware components at
https://www.juniper.net/customers/csc/management/updateinstallbase.jsp .
Failure to do so can result in significant delays if you need replacement parts.
This note does not apply if you replace existing components with the same
type of component.
Related
Documentation
Installing and Removing QFX3100 Director DeviceHardware Componentson page309•
Understanding Redundancy of QFX3100 Director Device Components and Functionality
The QFX3100 Director device is designed to provide redundancy in platforms and
components to minimize the possibility that a single point of failure can cause an entire
QFX3000 QFabric system to fail.
Two QFX3100 Director devices are connected together in a QFX3100 Director group to
provide control plane and management network redundancy for a QFX3000 QFabric
system.
The hardware components of a single QFX3100 Director device are also designed for
redundancy to minimize the possibility that a single point of failure causes a Director
device to fail.
This topic describes:
•
QFX3100 Director Device Redundancy on page 24
•
QFX3100 Director Device Component Redundancy on page 25
QFX3100 Director Device Redundancy
Two QFX3100 Director devices are connected together in a QFX3100 Director group to
provide control plane and management network redundancy for a QFX3000 QFabric
system. When one QFX3100 Director device fails, the second QFX3100 Director device
in the QFX3100 Director group continues to operate with minimal network disruption.
