CHAPTER 19
Installing a QFX3008-I Interconnect
Device
•
Installing and Connecting a QFX3008-I Interconnect Device on page 223
•
Unpacking a QFX3008-I Interconnect Device on page 224
•
Parts Inventory (Packing List) for a QFX3008-I Interconnect Device on page 225
•
Installing QFX3008-I Interconnect Device Mounting Hardware on Four-Post Racks or
Cabinets on page 227
•
Installing QFX3008-I Interconnect Device Mounting Hardware on Two-Post
Racks on page 231
•
Mounting a QFX3008-I Interconnect Device on a Rack or Cabinet Using a Mechanical
Lift on page 234
•
Connecting Earth Ground to a QFX3008-I Interconnect Device on page 237
•
Connecting AC Power to a QFX3008-I Interconnect Device with Single-Phase Wiring
Trays on page 239
•
Preparing Delta and Wye Three-Phase Power Cords on page 241
•
Connecting AC Power to a QFX3008-I Interconnect Device with Three-Phase Delta
Wiring Trays on page 246
•
Connecting AC Power to a QFX3008-I Interconnect Device with Three-Phase Wye
Wiring Trays on page 250
•
Powering On a QFX3008-I Interconnect Device on page 253
Installing and Connecting a QFX3008-I Interconnect Device
Before you begin, ensure that the installation site meets the requirements described in
“Site Preparation Checklist for a QFX3008-I Interconnect Device” on page 84.
To install and connect a QFX3008-I Interconnect device:
1. Follow the instructions in “Unpacking a QFX3008-I Interconnect Device” on page 224.
2. Install the mounting hardware on your four-post or two-post rack or cabinet by
following the instructions in “Installing QFX3008-I Interconnect Device Mounting
Hardware on Four-Post Racks or Cabinets” on page 227 or “Installing QFX3008-I
Interconnect Device Mounting Hardware on Two-Post Racks” on page 231.
223Copyright © 2012, Juniper Networks, Inc.
