Related
Documentation
Removing a Fan Module from a QFX3100 Director Device on page 312•
• Rear Panel of a QFX3100 Director Device on page 26
Removing a Network Module from a QFX3100 Director Device
QFX3100 Director devices support up to two network modules on the front panel. The
network modules are field-replaceable units (FRUs).
NOTE: The Director device requires powering off beforeinstallation or removal
of the network module.
Before you begin removing a network module from a QFX3100 Director device:
•
Ensure that you understand how to prevent electrostatic discharge (ESD) damage.
See “Prevention of Electrostatic Discharge Damage” on page 192.
Ensure that you have the following parts and tools available:
•
ESD grounding strap
•
Phillips (+) screwdriver, number 2
•
Antistatic bag or antistatic mat
To remove a network module from a QFX3100 Director device (see Figure 92 on page 316):
1. Attach the ESD grounding strap to your bare wrist, and connect the strap to a site ESD
point.
2. Place the antistatic bag or the antistatic mat on a flat, stable surface.
3. Power off the Director device. See “Powering Off a QFX3100 Director Device” on
page 295
4. Unscrew both captive screws counterclockwise using your fingers. If you are unable
to easily unscrew the captive screws with your fingers, use the screwdriver.
5. Gently pull the network module toward you and out of the network module slot, being
careful to keep one hand underneath the module to support it when it is removed
from the chassis.
6. Place the network module in the antistatic bag or on the antistatic mat.
315Copyright © 2012, Juniper Networks, Inc.
Chapter 25: Replacing QFX3100 Components
