6. Place one of the spacer bars over an ear of the installed large shelf. Position the notch
in the rear of the spacer bar so the upper part of the bar is flush with the rack rail and
the lower part is flush with the ear of the shelf.
7. Insert a mounting screw into each of the nonthreaded holes in the recesses of the
spacer bar to secure the spacer bar.
8. Repeat Step 6 and Step 7 for the other spacer bar.
9. Tighten all the screws completely.
Removing the Adjustable Center-Mounting Brackets for QFX3008-I Interconnect Device
Four-Post Rack or Cabinet Mounting
Before you begin, ensure that you have a number 2 Phillips (+) screwdriver.
To remove the adjustable center-mounting brackets:
1. Loosen the three screws at the top and bottom of each bracket.
2. Remove the center-mounting brackets.
TIP: Save the center-mounting brackets and screws in case you need to
move the device to a two-post rack at a later time.
Related
Documentation
Site Preparation Checklist for a QFX3008-I Interconnect Device on page 84•
Installing QFX3008-I Interconnect Device Mounting Hardware on Two-Post Racks
Before you install the QFX3008-I Interconnect device in a two-post rack, you must first
install mounting hardware on the rack (see Figure 61 on page 232). The spacer bars are
not needed for this mounting option; however, you can leave them attached to the
front-mounting brackets.
NOTE: In a rack, the device uses 21 U. You can mount two QFX3008-I
Interconnectdevices on a 42 U rackprovided that the racks meet the strength
requirements to support the combined weight of the devices. If you are
mounting two QFX3008-I Interconnect devices on a rack, mount the first
device on the bottom of the rack.
231Copyright © 2012, Juniper Networks, Inc.
