Table 34: Optical Interface Support for 10-Gigabit Ethernet SFP+ Transceivers in QFX3500

Devices

Specifications

Ethernet

Standard

QFX-SFP-10GE-USRModel number10GBASE-SR

10 GbpsRate

LCConnector type

DualFiber count

850 nmTransmitter

wavelength

–7.3 dBmMinimum launch

power

–1.3 dBmMaximum launch

power

–11.1 dBmMinimum receiver

sensitivity

–9.9 dBmMaximuminput power

AvailableDOM support

Junos OS Release 11.1 or laterSoftware required

MMFMMFMMFFiber type

50/125 µm50/125 µm62.5/125 µmCore/cladding size

OM3

(OM4 compatible)

OM2OM1Fiber grade

1500 MHz/km500 MHz/km200 MHz/kmModal bandwidth

100 m (328 ft)30 m (98 ft)10 m (32 ft)Distance
