Figure 15: AC Power Supplies
g005109
Ejector
lever
Status
LED
Handle
Fan
Each power supply has its own fan and is cooled by its own internal cooling system. Hot
air exhausts from the rear of the chassis.
A QFX3100 Director device supports two 560-W AC power supplies.
Related
Documentation
• Installing a Power Supply in a QFX3100 Director Device on page 311
• AC Power Specifications for a QFX3100 Director Device on page 135
• AC Power Supply LED on a QFX3100 Director Device on page 384
