Table 34: Optical Interface Support for 10-Gigabit Ethernet SFP+ Transceivers in QFX3500

Devices (continued)

Specifications

Ethernet

Standard

QFX-SFP-10GE-LRModel number10GBASE-LR

10 GbpsRate

LCConnector type

1310 nmTransmitter

wavelength

–8.2 dBmMinimum launch

power

0.5 dBmMaximum launch

power

–18 dBmMinimum receiver

sensitivity

0.5 dBmMaximuminput power

AvailableDOM support

Junos OS Release 11.1 or laterSoftware required

SMFFiber type

9/125 µmCore/cladding size

–Modal bandwidth

10 km (6.2 miles)Distance
