15 - 4 BeneVision N22/N19 Patient Monitor Operator’s Manual
15.5 NIBP Display
The NIBP display shows only numerics.
• If NIBP measurement fails, “XX” is displayed; if NIBP measurement is not taken, “--” is displayed.
• Outlined NIBP numerics indicate that the measurement is old and exceeds the set time. So these
NIBP values are not recommended for reference.
15.6 Preparing for NIBP Measurements
15.6.1 Preparing the Patient for NIBP Measurements
In normal use, perform NIBP measurement on a patient who is in the following position:
■ Comfortably seated
■ Legs uncrossed
■ Feet flat on the floor
■ Back, arm and feet supported
• It is recommended that the patient calms down and relaxes as much as possible before performing
the measurement and that the patient do not talk during the measurement.
• It is recommended to have the patient sit quietly for several minutes before taking the
measurement.
• Other factors that have been shown to result in an overestimation of blood pressure are labored
breathing, full bladder, pain etc.
(3) (4) (5)
(10) (9)
(2)
(1)
(6)
(7)
(8)
(1) Systolic pressure alarm limits (2) NIBP unit: mmHg or kPa
(3)The last NIBP measurement time (4) Time to the next measurement (for Auto mode only)
(5) Measurement mode: for Auto NIBP, interval
is displayed (6) Diastolic pressure
(7) Diastolicpressure alarm limit (8) Mean pressure alarm limit
(9) Mean pressure (displayed after measurement completed) or cuff pressure (displayed during the measurement)
(10) Systolic pressure
