BeneVision N22/N19 Patient Monitor Operator’s Manual 29 - 3
6. Turn on both monitors.
NOTE
• For the ID adapter setup of the TOF-Watch SX monitor, see 8.5 Connecting an External Device.
29.4 NMT Parameters
TOF-Watch® SX monitor provides the following measurements:
â–  TOF-Ratio
â–  TOF-Count
â–  PTC
â–  Single
â–  Tskin
29.5 NMT Display
In the case that you take a measurement in TET50Hz mode, TET100Hz mode, DBS3.3 mode or DBS3.2 mode, only
mode label is displayed in the NMT numeric area, which is shown as follows:
(1) Parameter unit (2) Parameter label
(3) Parameter measurement (4) Response amplitude of stimulation
(5) Skin temperature (6) Measurement interval
(7) Measurement countdown (8) Time of last measurement
(9) Time of last measurement (10) Measuring mode (11) Skin temperature
(1)
(6)
(5)
(8)
(7)
(2) (3)
(4)
(11)
(9)
(10
