BeneVision N22/N19 Patient Monitor Operator’s Manual 7 - 7
7.5.2 System Responses after Pairing the BP10 with the Monitor
This section describes system responses at the monitor and at the BP10 after pairing.
7.5.2.1 System Responses at the Monitor after Pairing the BP10 with the Monitor
Once a BP10 is paired successfully with the monitor, the monitor responds as below:
■ In the Wireless Module menu, the Add button on the right of the paired BP10 changes to Remove. The
symbol displays on the left of Remove.
■ The NIBP label on the monitor screen is suffixed with “-T”, indicating that measurement values come from
the BP10 device, as shown below.
■ The Sequence and ABPM tabs are added to the NIBP menu. You can perform NIBP measurement in
sequence or ABPM (Ambulatory Blood Pressure Monitoring) mode.
7.5.2.2 System Responses at the BP10 after Pairing the BP10 and the Monitor
Once a BP10 is paired successfully with the monitor, the BP10 responds as below:
■ The symbol is changed to in the prompt message area.
■ The BP10 allows you to start or stop NIBP measurement by pressing the start or stop NIBP button on the
front panel of the BP10. But it does not allow you to change any settings.
7.6 Unpairing the BP10 and the Monitor
You can unpair the BP10 and the monitor either via the monitor or via the BP10.
7.6.1 Unpairing via the Monitor
To unpair the BP10 and the monitor, follow this procedure:
1. Select the Main Menu quick key → turn to the second page → select Wireless Module from the Parame-
ters column.
2. Select the desired BP10.
3. Select Remove.
Upon completion of unpairing, the message Disconnection Completed appears on the monitor screen.
7.6.2 Unpairing via the BP10
To unpair the BP10 and the monitor, press the MPAN button on the right panel of the BP10.
7.6.3 System Responses after Unpairing the BP10 and the Monitor
This section describes system responses at the monitor and at the BP10 after unpairing.
7.6.3.1 System Responses at the Monitor after Unpairing the BP10 and the Monitor
Once a BP10 is unpaired successfully with the monitor, the monitor responds as below:
■ In the Wireless Module menu, the Remove button on the right of the unpaired BP10 changes to Add. The
symbol disappears.
