A - 10 BeneVision N22/N19 Patient Monitor Operator’s Manual
A.13.2 MPAN Performance Specifications
A.14 Measurement Specifications
The adjustable range of alarm limits is the same with the measurement range of signals unless otherwise
specified.
A.14.1 ECG Specifications
System capacity and
resistance to wireless
interference
When the following conditions exist simultaneously:
■ Five pairs of monitors and telemetry devices can communicate in 10 m
2
space,
with the monitors communicating with the Central Station via Wi-Fi. Note that the
telemetry devices can be devices such as TM80 and BP10.
■ The distance between the interfering devices and the monitor is greater than 20
cm. The interfering devices include but are not limited to: MPAN devices, remote
controllers, microwave ovens, interphones, operator’s network devices, cordless
phones, and ESU equipment.
the following requirements must be met:
■ The distinct vision distance between the monitor and the BP10 or the TM80 shall
be greater than or equal to 5 meters.
■ The code error rate of MPAN communication: ≤ 0.1%.
■ The data delay: < 1.5 seconds
MPAN network stability When five pairs of monitors and telemetry devices communicate in 10 m
2
space and the
monitors are communicating with the Central Station via Wi-Fi, the following
requirement must be met:
■ The time percentage when a monitor encounters MPAN communication loss shall
not exceed 0.1% over a 24-hour period.
■ The distinct vision distance between the monitor and the BP10 or the TM80 shall
be greater than or equal to 5 meters.
ECG
Standards Meet standards of IEC 60601-2-27 and IEC 60601-2-25
Lead set 3-lead: I, II, III
5-lead: I, II, III, aVR, aVL, aVF, V
6-lead: I, II, III, aVR, aVL, aVF, Va, Vb
12-lead: I, II, III, aVR, aVL, aVF, V1 to V6
ECG standard AHA, IEC
Display sensitivity 1.25 mm/mV (X0.125), 2.5 mm/mV (X0.25), 5 mm/mV (X0.5), 10 mm/mV (X1),
20 mm/mV (X2), 40 mm/mV (X4), Auto, less than 5% error
Sweep speed 6.25 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s, less than 10% error
Bandwidth (-3dB) Diagnostic mode:
Monitor mode:
Surgical mode:
ST mode:
0.05 to 150 Hz
0.5 to 40 Hz
1 to 20 Hz
0.05 to 40 Hz
Common mode rejection ratio
(with Notch off)
Diagnostic mode:
Monitor mode:
Surgical mode:
ST mode:
>90 dB
>105 dB
>105 dB
>105 dB (with Notch on)
Notch 50/60 Hz
Monitor, surgical, and ST mode: Notch turns on automatically
Diagnostic mode: Notch is turned on/off manually
