BeneVision N22/N19 Patient Monitor Operator’s Manual 2 - 3
2.3 System Components
The monitor consists of the main unit, primary display, secondary displays, external modules, satellite module
rack (SMR), input devices, and output devices.
NOTE
• Your monitor may not include all these components. Contact your local service personnel for the
available components.
2.3.1 Main Unit
The main unit processes data from modules.
2.3.1.1 Main Unit for Combined Installation
If the main unit and the primary display are combinedly installed. It provides the following connectors:
Bottom View:
(1) (2)
(3)
(4)
(5) (6) (7) (8) (9)
(10)
(11)
