31 - 12 BeneVision N22/N19 Patient Monitor Operator’s Manual
To view these events, follow this procedure:
1. Enter the desired review page by one of the following methods:
◆ Select the Review quick key → select the desired tab.
◆ Select the Main Menu quick key → from the Review column select the desired menu item.
2. View events by one of the following methods:
â—† Select .
â—† Select or to view the previous or next event.
31.3 Minitrends Window
The minitrends window shows graphic minitrends of parameters.
31.3.1 Entering the Minitrends Window
Choose one of the following methods to enter the minitrends window:
â– Select the Minitrends quick key. For how to set the Minitrends quick key, see 3.6.3.2 Configuring the
Displayed Quick Keys
.
■Select the Screen Setup quick key → select Minitrends.
■Select the Main Menu quick key → from the Display column select Choose Screen → select Minitrends.
In the minitrends window, parameter labels are displayed above trend data. Scales are displayed on the left of
trend data. Time length is displayed at the bottom of the minitrends window.
31.3.2 Setting Parameters
To set parameters, follow this procedure:
1. Enter the minitrends window.
2. Select the minitrends area to enter the
Minitrend Setup menu.
3. Set parameters. If you want to use the default parameters, select
Default Parameter.
31.3.3 Setting the Minitrend Length
To set the minitrend length, follow this procedure:
1. Enter the minitrends window.
2. Select the minitrends area to enter the
Minitrend Setup menu.
3. Set
Minitrend Length.
31.3.4 Exiting the Minitrends Window
Choose one of the following methods to exit the minitrends window:
■Select the Screen Setup quick key → select the desired option.
■Select the Main Menu quick key → from the Display column select Choose Screen → select the desired
option.
