BeneVision N22/N19 Patient Monitor Operator’s Manual 8 - 5
• First installation and debugging should be executed by Mindray service personnel or authorized
technician.
• Please check the compatibility of the external device and the ID adapter before connection.
Otherwise, unpredictable system failure may be resulted.
• Ports on the BeneLink module are not conventional network connectors. They are intended for
connecting with the serial port of designated devices only. Do not connect them to public network
interfaces.
8.5.1 Configuring the ID Adapter
The ID adapter has already been correctly configured before leaving the factory. If you want to re-configure the
ID adapter, follow this procedure.
1. Select the Main Menu quick key → turn to the third page → from the System column select Maintenance
→ input the required password → select Ok.
2. Select Upgrade ID module.
3. Select Benelink Module Port to define which port the RJ45 connecting cable is connected to. You must
connect the RJ45 connecting cable to the selected port when re-configuring the ID adapter. Otherwise, ID
adapter re-configuration will fail.
4. Select ID to configure a new ID to the ID adapter.
8.5.2 ID Adapter IDs
External Device ID for ID adapter Type of serial port adapting cable
Anesthesia machine
Draeger Fabius GS/Plus/Tiro 4446BBBA Fabius GS: No need to use the adapting
cable.The ID adapter can be plugged into the
serial port of the external device directly.
Fabius Plus: Type C
Fabius Tiro: Type C
GE Avance Carestation /Aisys 4F41B0BF Type D
GE Aestiva 7100/7900 4F37B0C9 Type D
Mindray Wato20/25/30/35/50/55/
60/65
4D52B2AE No need to use the adapting cable: the ID
adapter can be plugged into the serial port of
the external device directly.
Mindray A3/A5/A7
Ventilator
Carefusion Vela 564ca9b4 Type E
Draeger Evita 2 / Evita 2 dura /
Evita 4/ Evita XL
4434BBCC Type B
Draeger Primus 4450BBB0 Type C
GE Engström Carestation (Neo), GE
Engström Carestation (Pro)
4F45B0BB Type B
Hamilton C2 3270CD90 Type B
Hamilton G5 (protocol Block) 3542CABE Type B
Hamilton G5 (protocol Polling) 3550CAB0 Type B
Hamilton Galileo 4750B8B0 Type B
