8 - 6 BeneVision N22/N19 Patient Monitor Operator’s Manual
8.6 Devices Integrated Window
You can view the information of external devices from the Integrated Devices window. The Integrated Devices
window provides information of both individual device and multi devices. In the individual device menu, you can
select Select Parameter, Unit and Alarm to set the parameters to be displayed, parameter units and view the
alarm list.
The parameters in the Integrated Devices window are displayed in the order of priorities. If the window cannot
display all the selected parameters, only parameters with higher priorities are displayed. Please see the following
sections for parameter priorities.
â– For the parameters measured by the external device, the measurements display directly after the parameter
labels.
Maquet Flow-i 4D46B2BA Type B
Maquet Servo-i/Servo-s 4D53B2AD Type B
Mindray E3/E5 4D56B2AA No need to use the adapting cable: the ID
adapter can be plugged into the serial port of
the external device directly.
Mindray SV300
Newport E360 4E50B1B0 Type B
Philips Respironics V60 VPRT: 5637A9C9
SDNA:5636A9CA
Type B
Puritan Bennett 840 SNDF: 5042AFBE(recommended)
SNDA: 5031AFCF(support less
parameters than protocol SNDF)
No need to use the adapting cable: the ID
adapter can be plugged into the serial port of
the external device directly.
TOF-Watch® SX 5457ABA9 Type C
TCM CombiM/TCM TOSCA 5443ABBD Type C
Serial port adapting cable PN Remark
Type A 009-001767-00 Male to female
Type B 009-001768-00 Male to male
Type C 009-001769-00 Male to male
Type D 009-002943-00 9-pin to 15-pin
Type E 009-004613-00 9-pin to RJ45 connector
External Device ID for ID adapter Type of serial port adapting cable
