A - 18 BeneVision N22/N19 Patient Monitor Operator’s Manual
A.14.7 IBP Specifications
A.14.8 C.O. Specifications
Standard Meet the standard of IEC 60601-2-34.
Technique Direct invasive measurement
IBP
Measurement range -50 to 360 mmHg
Resolution 1 mmHg
Accuracy ±2% or ±1 mmHg, whichever is greater (without sensor)
Refreshing rate 1 s
PPV
Measurement range 0% ~ 50%
Pressure transducer
Excitement voltage 5 VDC, ±2%
Sensitivity 5 V/V/mmHg
Zero adjustment range ±200 mmHg
Impedance range 300 to 3000
Volume displacement (ABBOTT) <0.04 mm
3
/100 mmHg
Alarm limit Range (mmHg) Step (mmHg)
Sys High IBP ≤ 50: (low limit + 2) to 50
IBP > 50: (low limit + 5) to 360
IBP ≤ 50: 1
IBP > 50: 5
Mean High
Dia High
Sys Low IBP ≤ 50: -50 to (high limit - 2)
IBP > 50: -50 to (high limit - 5)
Mean Low
Dia Low
Measurement method Thermodilution method
Measurement range C.O.:
TB:
TI:
0.1 to 20 L/min
23 to 43 °C
0 to 27 °C
Resolution C.O.:
TB, TI:
0.1 L/min
0.1 °C
Accuracy C.O.:
TB, TI:
±5% or ±0.1 L /min, whichever is greater
±0.1 °C (without sensor)
Repeatability C.O.: ±2% or ±0.1 L/min, whichever is greater
Alarm range TB: 23 to 43 °C
Alarm limit Range Step
TB High (low limit + 1) to 43 °C
(low limit + 1.8) to 109.4 °F
0.1 °C
0.1 °F
TB Low 23 to (high limit - 1) °C
73.4 to (high limit - 1.8) °F
