31 - 10 BeneVision N22/N19 Patient Monitor Operator’s Manual
31.2.9 ST Review Page
When ST analysis is enabled, you can review ST templates on the ST review page.
31.2.9.1 Entering the ST Review Page
Choose one of the following methods to enter the ST review page:
■Select the Review quick key → select ST.
■Select the Main Menu quick key → from the Review column select ST.
31.2.9.2 Setting the ST Reference Template
You can set the desired ST template group as reference template. To set the ST reference template, follow this
procedure:
1. Enter the ST review page.
2. Select
Set Reference.
• The baseline template is used as the reference template by default.
31.2.9.3 Displaying/Hiding the ST Reference Template
To display or hide ST reference template, follow this procedure:
1. Enter the ST review page.
2. Select
Display Reference or Hide Reference.
â—† Display Reference: the ST template storage time is displayed on the right of current segment and ST
values are also displayed on the reference template.
â—† Hide Reference: the ST template storage time and ST values are not displayed.
31.2.9.4 Displaying/Hiding Markers
To display or hide markers, follow this procedure:
1. Enter the ST review page.
2. Select
Display Marker or Hide Marker.
â—† Display Marker: a white vertical bar appears above each waveform, marking the positions of ISO, J
point, and ST point.
â—† Hide Marker: the positions of ISO, J point, and ST point are not displayed.
31.2.9.5 Printing a ST Template
To print a ST template, follow this procedure:
1. Enter the ST review page.
2. Select .
To Next Page
