19 - 8 BeneVision N22/N19 Patient Monitor Operator’s Manual
• The SVRI unit changes accordingly after the SVR unit is changed.
19.7.3 Setting Parameters for Display
To set the parameters for display, follow this procedure:
1. Select the CCO numeric area to enter the
CCO menu.
2. Select the
Select Parameter tab.
3. Select the primary and secondary parameters for display.
19.7.4 Setting the CCO Analog Output Signal
To set the CCO output signal, follow this procedure:
1. Select the CCO numeric area to enter the
CCO menu.
2. Select the
Signal Output Setup tab.
3. Set the output signal as follows:
â—† This monitor can output the analog signals of ECG waveform, MAP value, SpO
2
value and CVP value to
the Vigilance II monitor. If a signal has several sources, you can select a source.
â—† This monitor can output the CVP analog signal to the Vigileo monitor. If the CVP signal has several
sources, you can select a source.
â—† Select Simulated High Value to output the simulated high value calibration signals to Vigilance II or
Vigileo monitor. To stop output the simulated high value signal, select
Simulated High Value again.
â—† Select Simulated Low Value to output the simulated low value calibration signals to Vigilance II or
Vigileo monitor. To stop output the simulated low value signal, select
Simulated Low Value again.
The following table shows values and voltages of the high and low value calibration signals.
• The calibration voltage of Vigilance II or Vigileo monitor should be the same as the output voltage of
this monitor. Otherwise, some parameter values may be incorrectly calculated.
• See the operator’s manuals of Vigilance II and Vigileo monitors for the calibration instructions.
Parameters Parameter Values Output Voltage
High Value Calibration Signals
MAP 500 mmHg 5V
SpO
2
100% 10V
CVP 100mmHg 5V
Low Value Calibration Signals
MAP 0 mmHg 0V
SpO
2
0% 0V
CVP 0mmHg 0V
